Fir-Tree Thread Type Locknut, Metric

Fir-Tree Thread Type

Style AC

Style DO

Style DS

Style RF


Basic Part Numbers
Nom.Dia. mm Pitch mm Hex-W mm Flange Dia.-D mm Height-H mm Material Thickness mm Tightening Torque *Nm Clamping Force *N
AC051611
 5
 1.6
 11
 -
 9.45
 0.46
 2.25
 1560
DO051614
 5
 1.6
 10
 14
 6.40
 0.46
 4.50
 1110
DO051619
 5
 1.6
 10
 19
 7.35
 0.46
 6.80
 1110
DS051614
 5
 1.6
 10
 14
 10.7
 0.43
 4.50
 1110
RF051611
 5
 1.6
 11
 -
 3.05
 0.43
 2.25
 1560

*N - Newtons = 9.8 Kgm  *Nm - Newton meters = 980 Kgm-Cm

Palnut metric fasteners

Fir-Tree Thread Type Locknuts
